LED Panel | Replacement for grille luminaires UGR<19 | 28-35W | 620x620 | CCT 3000K-3500K-4000K e.g. for Odenwald ceiling
Couldn't load pickup availability
LED Panel U29-35 for suspended grid ceilings (Odenwald ceilings), UGR<19, 3 CCT, 28–35 W, incl. power supply
This modern LED panel light offers maximum flexibility and user-friendliness for professional lighting solutions. Thanks to innovative technology, both the color temperature and the wattage can be adjusted directly on the panel – without any additional accessories.
Three selectable color temperatures (3,000 K, 3,500 K, 4,000 K) allow for adaptation to various applications – from cozy warm to functional neutral white. The wattage is adjustable in four levels between 28 and 35 watts.
With a luminous efficacy of over 120 lm/W on average, the panel ensures energy-efficient, uniform illumination. The integrated microprismatic diffuser (UGR<19) reduces glare and thus meets the highest demands for visual comfort – ideal for offices, meeting rooms, educational institutions, and other work environments.
The panel is designed to fit standard suspended grid ceilings (Odenwald ceilings, 625 x 625 mm) and can be installed directly without additional accessories. The appropriate power supply is included in the scope of delivery – for immediate, uncomplicated commissioning.
✔ Adjustable color temperature: 3,000 K / 3,500 K / 4,000 K
✔ Power regulation: 28 W / 30 W / 32 W / 35 W
✔ Efficient: >120 lm/W
✔ Low glare: UGR<19
✔ Incl. power supply
✔ Suitable for Odenwald ceiling / Grid size 625 x 625 mm
✔ 5 years warranty
| GENERAL DATA | |
|---|---|
| Color | white |
| Mounting location | Ceiling mounting |
| Application area | indoor |
| Min. installation distance to illuminated object | 0.5m |
| Dimmable | no |
| Must not be covered with thermal insulation material | yes |
| Power supply included | yes |
| Length [mm] | 620 |
| Width [mm] | 620 |
| Height [mm] | 32 |
| Integrated LED light source | yes |
| TECHNICAL DATA | |
| Rated voltage [V] | 220-240 AC |
| Rated frequency [Hz] | 50 |
| Maximum power [W] | max 35 |
| Protection class against electric shock | II |
| Cover material | plastic |
| Diode type | LED SMD |
| Luminous flux of the luminaire [lm] | 3900 / 4200 / 4200 |
| Color temperature | warm white, white |
| Correlated Color Temperature [K] | 3000 / 3500 / 4000 |
| Color consistency in MacAdam ellipses | 6 |
| Color rendering index | 80 |
| Lifespan [h] | 50000 |
| Number of switching cycles | ≥50000 |
| Beam angle [°] | 90 |
| Ambient temperature range [°C] | 5÷25 |
| Housing material | steel |
| Panel/frame material | steel |
| Connection type | Self-clamping terminal block |
| Cross-section area of used wires [mm²] | 0.5-2.5 |
| IP class (protection rating) | 20 |
| UGR | <19 |
