Item description:
- These great beams are the perfect lighting for cafes, hotel rooms and your home.
- Must not be covered with heat-insulating material, we recommend the use of a spacer .
- Bulbs can be replaced.
- If you only have a small installation depth available, we recommend using recessed spotlights with extra-flat LED modules .
- Delivery includes GU10 and GU5.3 socket, without bulb.
Technical data:
| Color: | matte white |
| Necessary use of self-shielding lamps : | Yes |
| Installation location : | Ceiling installation |
| Scope of application : | within |
| Min. installation distance to the illuminated object : | 0.5m |
| Replaceable lamp/light source : | Yes |
| Suitable for installation on a normally flammable surface : | >35W |
| Must not be covered with heat insulating material : | Yes |
| Light source in the set : | no |
| Length [mm] : | 90 |
| Width (mm] : | 90 |
| Height (mm) : | 26 |
| Mounting hole [mm] : | Ø80 |
| Cable length [m] : | 0.12 |
| Nominal voltage [V] : | 12 AC; 12 DC/ 230V |
| Maximum power [W] : | max.50 |
| Protection class against electric shock : | III |
| Light sources : | MR16 |
| Base : | GU5.3 / GU10 |
| Ambient temperature range [°C] : | 5÷25 |
| The luminaire is designed for lamps/light sources of the following energy efficiency classes : | A++, A+, A, B, C, D, E |
| Housing material : | Aluminium alloy |
| Connection type : | free cable ends |
| Cable diameter [mm²] : | 0.75 |
| Angle adjustment of the lamp : | in one axis |
| Angle adjustment of the lamp [°] : | 30 |
| IP class (protection class) : | 20 |
| Weight [g] : | 150 |
